JXM1 Moulded Case Circuit Breaker

JXM1 series moulded case circuit breaker is one of products developed and manufactured by adopting international advanced technology. It is supplied with rated insulating voltage 500 and 800V and used for circuit of AC 50/60Hz, rated operating voltage AC 400V (or below), rated operating current up to 1600A for infrequent changing over and starting of the motors.The products conforms to IEC60947-2 standard.

Get Quote

Basic Specification and Main Parameters

Type	Rated Current(A)	Pole	Rated Insulanting Voltage(V)	Rated Operating Voltage(V)	Arcing over Distance(mm)	Ultimate Short circuit breaking capacity (kA)	Servies short circuit breaking capacity (kA)	Operation performance		Utilization category
Type	Rated Current(A)	Pole	Rated Insulanting Voltage(V)	Rated Operating Voltage(V)	Arcing over Distance(mm)	Ultimate Short circuit breaking capacity (kA)	Servies short circuit breaking capacity (kA)	Load	Unload	Utilization category
JXM1-63L	(6), 10, 16, 20, 25 32, 40, 50, 63	3,4	500V	400V	0	35	22	1500	8500	A
JXM1-63M	(6), 10, 16, 20, 25 32, 40, 50, 63		500V	400V	0	50	35
JXM1-125L	(10), 16, 20, 25, 32, 40, 50, 63, 80, 100, 125		800V	400V 690V	0(≤50)	35	17.5
JXM1-125M					0(≤50)	65	42.5
JXM1-125H					0(≤50)	85	50	1000	7000
JXM1-250L	100, 125, 160, 180, 200, 225, 250				≤50	35	18
JXM1-250M					≤50	65	42.5
JXM1-250H					≤50	85	50	1000	4000
JXM1-400L	250, 315, 350, 400				≤50	50	25
JXM1-400M					≤100	70	50
JXM1-400H					≤100	100	65
JXM1-630L	400 500 630				≤100	50	25
JXM1-630M					≤100	70	50
JXM1-630H					≤100	100	65
JXM1-800L	630,700,800		1000V		≤100	70	50
JXM1-1250LM	1000,1250				≤100	100	70
JXM1-1600LM	1600				≤100	150	70

Note: 6A without thermal protection.

The N-pole of four-poles breaker is sited at the right side of the product has four types:

Type A: Without current trip-lease on N pole which making all the time, not closing and opening with the other three poles.

Type B: Without current trip-release on N pole which closing and opening with the other poles.

Type C: With current trip-release which closing and opening with the other three poles.

Type D: With current trip-release which making all the time not closing and opening with the other three poles.

Protection Characteristic

The thermodynamic release of a circuit breaker provides the feature of inverse time-delay, while the magnetic release is the instantaneous operation as shown on table 2(distribution circuit breaker) and table 3 (motor protection circuit breaker).

Product Detail

Wide Handle

The smooth lines of the handle are consistent with the human body

Customary handle radian

Reduce the pressure of water chestnut on fingers

Better pull !

Arc Extinguishing Design

Plate back wiring and plug - in mounting.

Installation and debugging must be operated by

professionals to ensure the distance of flying foxes.

Current protection

Sensitive protection,quick disconnection
